Description

This is an electrically heated and insulated tubing bundle that uses HTSX self-regulating heat tracing, making it suitable for both freeze protection and medium-to-high process temperature maintenance up to 150°C (302°F). A key feature of HTSX is its ability to withstand high temperature exposure, making it ideal for lines subject to intermittent steam purging where temperatures can temporarily reach up to 250°C (482°F) (intermittent power-on or off) or 205°C (400°F) (continuous power-off). The self-regulating nature of the heater means its heat output automatically adjusts along its entire length in response to ambient or process temperature changes, which prevents overheating of the product.

Features

• Heat Trace Type: Uses HTSX self-regulating heat tracing, which automatically varies heat output.
• Maximum Maintain Temp: Can maintain process temperatures up to 150°C (302°F).
• High Temperature Capability: Can withstand intermittent exposure temperatures up to 250°C (482°F), suitable for applications involving steam purging.
• Installation: “Cut-to-length” feature allows for easy field fabrication and connections, minimizing waste.
• Safety: Low risk of overheating the tube or product due to the self-regulating technology.
• Certification: Approved for use in ordinary (non-classified) areas and hazardous (classified) areas.
