FAK-2 90° Elbow Seal Kit – Thermon

Description

The FAK-2 90° Elbow Seal Kit is a termination accessory designed to provide a watertight and insulated cover over a 90 degree bend or elbow in a TubeTrace or ThermoTube bundle. This kit is used when the tubing bundle must turn a corner or transition direction, allowing the bend to be formed in the field while maintaining the integrity of the weatherproofing and insulation, particularly where the pre-insulated jacket has been removed and reapplied.

Features

• Function: Provides a sealed and insulated enclosure for a 90 degree elbow in a tubing bundle run.
• Insulation Integrity: Ensures that the insulation thickness is maintained around the sharp bend, preventing cold or hot spots that could compromise freeze protection or process temperature maintenance.
• Weather Protection: Creates a watertight seal to prevent moisture and contaminants from entering the insulation layers through the field-formed corner.
• Components: Typically includes a UV-resistant shell (ABS plastic), internal insulating material, and sealants to completely encapsulate the elbow fitting and the termination ends of the jacket.
• Compatibility: Used with electrically heated (TubeTrace) or pre-insulated (ThermoTube) bundles.
